Stock Number JT9-892030
Amperage Draw @ 230V 3Ph 9
Compound Slide Travel (In.) 4
Cross Slide Travel (In.) 7
Drive EVS
Length of Gap (In.) 9
Model Number E-1440VS
Motor (HP) 3 HP, 230V, 3Ph
Number of Inch Threads 40.0000
"Number of Longitudinal }
and Cross Feed
Rates" 80
Number of Metric Threads 22.0000
Overall Dimensions
(L x W x H) (In.) 77 x 30 x 58
Prop 65 Cancer and Reproductive Harm
Range of Cross Feeds (IPR) 0.0003 - 0.01
Range of Inch Threads (TPI) 4 - 112
Range of Longitudinal Feeds
(IPR) 0.0012 - 0.0294
Range of Metric Threads 0.45 - 7.5
Range of Spindle Speeds
(RPM) 0 - 2,200
Size 14 x 40
Spindle Bore (In.) 1-1/2
Spindle Mount D1-4
Spindle Taper with Sleeve MT5
Steady Rest Capacity (In.) 1/4 - 2-3/4
Style (Type) ELITE EVS
Swing Over Bed (In.) 14
Swing Over Cross Slide (In.) 8-5/8
Swing Through Gap (In.) 20
Tailstock Spindle Travel (In.) 5
Taper in Tailstock Spindle MT3
Warranty 3 Year Elite
Weight (Lbs.) 1653
Width of Bed (In.) 8-1/2
Gross Weight 1800.0
Net weight 1800.0
