Stock Number JT9-321860 Bed Construction Cast Iron Bed Gap (In.) 8 Carriage Travel (In.) 72-1/2 Compound Slide Travel (In.) 5-1/2 Coolant Pump Motor 1/8 Diametral Pitch Threads Number 24.0000 Distance Between Centers (In.) 80 Drive Geared Head Gross Weight (Lbs) 9251 Input Power 230/460V, 3Ph Length of Gap (In.) 8 Max Tool Size (In.) 1-1/4 x 1-1/4 Model Number GH-2680ZH Motor Amps 25.4/12.7 Motor (HP) 10 HP, 230/460, 3 Ph Motor Power (HP) 10 Motor Voltage (V.) 230/460 Net Weight (Lbs.) 8514 Number of Inch Threads 48.0000 Number of Longitudinal and Cross Feed Rates 65 Number of Metric Threads 22.0000 Number of Spindle Speeds 12 Overall Dimensions (L x W x H) (In.) 138 x 43 x 57 Prewired Voltage (V.) 230 Prop 65 Cancer and Reproductive Harm Range of Cross Feeds (IPR) .010 - .0404 Range of Inch Threads (TPI) 2-30 Range of Longitudinal Feeds (IPR) .0023 - .0937 Range of Metric Threads 1 - 14 Range of Spindle Speeds (RPM) 36 - 1,600 Shipping Dimensions (L x W x H) (In.) 138 x 43 x 57 Size 26 x 80 Spindle Bore (In.) 4-1/8 Spindle Mount D1-8 Spindle Taper MT5 Spindle Taper with Sleeve MT-5 Steady Rest Capacity (In.) Small 25/32 - 4-29/32, Large 3-15/16 - 9-7/16 Style (Type) Engine - Large Spindle Bore Swing Over Bed (In.) 26 Swing Over Cross Slide (In.) 16-1/2 Swing Through Gap (In.) 34 Tailstock Spindle Travel (In.) 6 Taper in Tailstock Spindle MT-5 Type Large Spindle Bore Engine Lathe Weight (Lbs.) 8514 Width of Bed (In.) 16 Wiring Remarks Additional Fee required to rewire to 460V Follow Rest Capacity (In.) 25/32 - 3-15/16
